Mornsun’s new URF1D_LD-40WR3 series of 40W Rail R3 converters have been recently released, to extend their 6W-20W range of RAIL R3 DC converters. The new URF1D_LD-40WR3 series offer, a wide input voltage range of 40-160VDC need to suit 72V, 96V, 110V voltages used in the railway industry with 3KVDC/1.5KVAC isolation ensures they comply with Rail/Locomotive EN50155 standard requirements and EN62368 standards. The devices have -40c ~ +85c wide operating temperature with UVP, OSC, OCP, OVP and OTP protection in an industry standard 50.8x25.4x11.8mm DIP housing & pin connection. The URF1D_LD-40WR3 series has an optional heat sink in PCB mount, along...

Offer solutions to 3 common issues with power supply design. Short circuit protection where large capacitive loads make it difficult to coexist Focus on high efficiency at full load whilst ignoring efficiency at low load, standby current power consumption In situations where large capacitors cannot be used as it may cause start up failure or destroy the converter MORNSUN’s fixed input voltage DC/DC converters R3 series have adopted IC technologies that decouple these conflicts whilst maintaining continuous short-circuit protection, capacitive load and start-up capability which greatly resolves problems existing in the design. Mornsun’s fixed input range of 1W DC/DC R3 Converters free up your time from...

MORNSUN continues to expand its existing range packages of (DIP24, 1*1 and 2*1) DC/DC Converters by developing an innovative new ultra-thin range of converters and continues to meet the demands for a more diverse range of applications. The 6W converter is only 31.60*18.10*6.10mm and the 10W is 39.20*20.80*6.10mm with packages available in SMD, DIP , open frame and metal case. The new SMD 6W and 10W DC/DC Converters performance features all the new R3 series advantages, with 500VAC isolation , up to 88% efficiency, no-load power consumption as low as 0.096W, multiple protections including SCP, OCP, OVP & input UVP....

MORNSUN has extended 24V input voltage to 4:1 isolated regulated DC/DC converters with a 100W series. The New URF24_QB-100WR3 series offers a wide input range of 9-36VDC & isolation of 2250VDC along with input UVP, SCP, OCP, OVP and OTP protections, meets EN62368 & EN50155 & EMI meets CISPR22/EN55022 CLASS B standards The “¼ Brick” package has International standard pin-outs and can be supplied without a base mount that makes thermal heat sink connection possible through the base, the device also has a heatsink option. Additional to being used in traditional industry applications, such as industrial, communications, power grid and rail...

This 20W range has been added due to market demand for dual output devices (positive and negative) & extends MORNSUN’s 6-20W rail R3 DC/DC converters. These converters provide a wide input voltage range of 40-160VDC due to input voltages of 72V, 96V, 110V used in the railway industry. Positive and negative outputs and 3KVDC isolation voltage ensures they meet railway EN50155 standard requirements. The URE1D_LD-20WR3 series has input UVP, OSC, OCP and OVP protections. The 50x25mm (2”x1”) international standard package is available in PCB mount, Chassis & DIN-Rail mounting with heatsink options making the series widely suitable for use in...
